In-Wall Wire Concealment in Santa Ana
TV Mounting Frame Santa Ana covers hiding TV cables in Santa Ana homes — rated in-wall kits in drywall rooms, painted raceways where the wall is plaster, brick or shared with a neighbor — so the picture hangs clean without a cord ever running loose inside a wall.
Bookings aren't open yet. Leave your name and number; your message is recorded, and you'll get one message when a local installer is available.
Illustration
Where a wall can be opened and where it cannot
| Wall | Usual route | Why |
|---|---|---|
| Drywall over studs | In-wall rated kit | The cavity between studs is open |
| Plaster over lath | Surface raceway, painted | Opening plaster risks the finish |
| Brick or concrete | Raceway or a drywall return | Masonry is not cut for wires |
| Shared party wall | Raceway, or another wall | CC&Rs often limit work in it |
| Rental wall | Raceway, with the landlord's answer | The lease decides on holes |
How a rated kit is fitted
An in-wall power kit carries power inside the wall through rated cable between two recessed boxes, one behind the TV and one near the outlet. HDMI uses CL3-rated cable. The installer checks for fire blocks in the stud bay, cuts two small openings, fishes the cable and closes the boxes with plates.
What the numbers show
- Upper recessed box A box behind the TV holds the plug that powers it.
- In-wall rated cable Cable rated for use inside walls; a plain cord is never used here.
- Lower inlet box A box near the floor takes the power from a normal outlet.
- Signal pass-through A brush-covered opening lets HDMI cables pass down the same bay.
- Stud bay The space between two studs; checked for fire blocks before cutting.
What needs an electrician
A new outlet behind the TV, a new circuit or any wiring beyond a rated relocation kit is electrical work that is permitted and inspected, and it belongs to an electrician. A mounted TV plugs into the outlet that is already there.
- Rated kit: moves the plug's location, a mounting-job item.
- New outlet: an electrician's job.
- Permit: electrical work behind a wall can need one; the electrician handles that side.
In-Wall Wire Concealment — common questions
Can the wires be hidden in a plaster wall?
Usually a painted raceway is the safer route, since opening plaster risks the finish.
Is an extension cord allowed inside a wall?
No. Only in-wall rated kits are used.
